Features:
Adopting a half-wave rectification control circuit, the feeding capacity can be steplessly adjusted within the rated output range. It can be integrated into automated production processes to achieve full production automation.
Upon customer request, an automatic amplitude stabilization control system can be provided, with the feeder's amplitude fluctuation ≤ ±3%. Equipped with a microcomputer control cabinet, it enables intelligent feeding with high stability.
Simple structure, light weight, no need for lubrication, and convenient maintenance.
Based on the principle of near-resonance, it boasts low energy consumption. Materials in the trough move in a micro-throwing mode, resulting in minimal wear of the trough.
Specification
| MODEL | CAPACITY(TPH) | FEEDING SIZE(MM) | POWER(KW) | WEIGHT (KG) | WEIGHT (KG) |
| GZ1 | 5 | 50 | 0.06 | 73 | 73 |
| GZ2 | 10 | 50 | 0.15 | 146 | 146 |
| GZ3 | 25 | 75 | 0.2 | 217 | 217 |
| GZ4 | 50 | 100 | 0.45 | 412 | 412 |
| GZ5 | 100 | 150 | 0.65 | 656 | 656 |
| GZ6 | 150 | 200 | 1.2 | 1252 | 1252 |
| GZ7 | 250 | 250 | 3 | 1920 | 1920 |
| GZ8 | 400 | 300 | 4 | 3040 | 3040 |
| GZ9 | 600 | 350 | 5.5 | 3750 | 3750 |
| GZ10 | 750 | 500 | 4*2 | 6495 | 6495 |
| GZ11 | 1000 | 500 | 5.5*2 | 7680 | 7680 |
