Slurry Pump

Introduction

AH series slurry pump are cantilever horizontal centrifugal slurry pumps. They are widely used in industry of mining, electrial power, metallurgy, coal, building materials etc for transporting high concentration slag slurry with strong abrasion. Mud pump, sand pump, dredge pump, sludge pump, impurity pump and desilting pump are all belong to category of slurry pump.

Application

• Mining and Mineral Processing: Handling abrasive slurries in coal, gold, copper, and iron ore mining.
• Dredging and Sand Extraction: Used in river, lake, and sea dredging operations.
• Power Plants: Desulphurization and ash handling systems.
• Chemical Industry: Pumping corrosive and abrasive fluids.
• Wastewater Treatment: Handling sludge and wastewater.

Features

• High concentration, volume concentration reach to 60%, weight concentration reach to 70%.
• Comprehensive performance is good, high head: long distance and high head transportion, single set head can reach to max 118m, and can be used in series to satisfy much higher head requirements.
• High flow rate capacity: can be reached 5400m3/h.
• Good passing ability:gravel pump max passing particles size is 380mm.
• Diameter size:outlet size from 1" to 18".
• High corrosion, abrasion resistance widely material optional: metal flow parts including: (Cr27Mo),(Cr30MoNi),(Cr30MoNiCu) and rubber material etc. PH value 1.0-14.
• Widely application: all slurry, mud and bad corrosive medium can be transported, widely used in industry of mining, electrical power, metallurgy,coal, construction etc.
• Driving engine of motor and diesel are available.
• Kinds of driving method satisfy different space need on site: DC, CL, CR, CV, ZV.
• Energy saving and cost reducing: pump itself water conservancy design advanced and mature. In the mode of traditional direct start increasing soft start and frequency start methods, it make sure energy saving and protection devices; Adjust the speed by soft connection mode in order to achieve the maximum utilization and tower results of work.
• Easy operation, lower noise and vibration.

Spare Parts

Impeller, Volute Liner, Casing, ThroatBush, Frame Plate Liner Insert, Cover Plate, Frame Plate, Pump Liner Expeller, Expeller Ring,Stuffing Box, Expeller, Pump Shaft, shaft sleeve, Shaft Spacer, Bearing Assembly, Base, Stuffing Box, Gland Assembly, Bearing Housing,Lantern Ring, pump discharge pipe, flange, and so on.

Materials and Durability

Wear-Resistant Materials: Components like impellers, liners, and throat bushes are often made from high-chrome alloys, rubber, or ceramics to withstand abrasive and corrosive conditions.

FAQ

What type Pump mainly produce?
Horizontal slurry pumps, vertical slurry pumps, rubber lined pumps, gravel sand pumps, froth pumps, desulfurization pumps, filter press feed pumps, dredge pumps, sewage pumps, submersible slurry pumps, and spare parts.
Can you provide OEM or ODM service?
Yes.
What is your warranty period?
One year.
What is your delivery time?
Normally within two weeks.
The Min MQQ?
The MQQ is one set of pump or spare parts.
